Complex Parts on VMCs: Dividing Heads and Angle Heads
Feature-rich parts beyond three faces: how CNC dividing heads, rotary units and right-angle heads turn a standard VMC into a flexible cell.
Parts with features on many faces, teeth, flats, cross-holes and inclined ports, do not automatically need a five-axis machine. A standard VMC plus the right accessories covers far more of that territory than buyers expect, at a fraction of the capital.
The Accessory Toolkit
- CNC dividing head: precise angular indexing for cross-holes, flats and tooth forms.
- Right-angle heads: reach side walls and internal features the vertical spindle cannot.
- Tool presetter and linear scales: keep long accessory-driven jobs dimensionally honest.
- Precision vises and collet chucks: fast changeovers between part families.
The workflow that works: index with the dividing head for each face group, then switch to an angle head for the features the vertical spindle cannot reach. With those two moves, a pump housing with bolt flanges, side ports and inclined lube holes finishes in one clamping cycle instead of three.
Accuracy tips are simple but strict: indicate the dividing head true before the first cut, verify angle head tool runout with a test bar, and record centre heights once per setup family.
