VTC-600 Drilling and Tapping Center: 20000 rpm, 48 m/min Rapids

The VTC-600 is the base model of VITOP Machinery's drilling and tapping center series, a machine class built for one purpose: drilling and threading small parts as fast as possible. Its specification reads differently from a general VMC, and understanding those differences shows where it saves money. Here is the breakdown.

Speed Where It Counts

The BT30 spindle reaches 20000 r/min, with an electric spindle option for shops running very small tools. Power is 5.5 kW, right-sized for hole making. What separates this machine from a small VMC in the same envelope is motion: rapid traverse is 48000 mm/min, or 48 m/min, on all three axes. On a part with hundreds of hole positions, non-cutting time dominates the cycle, and cutting feed of 15000 mm/min keeps positioning tight too. Positioning accuracy is ±0.003/300 mm with ±0.002/300 mm repeatability and a 0.001 mm minimum setting unit.

Key Specifications at a Glance

Work Envelope and Workholding

The 700x420 mm table carries parts up to 250 kg on three 14 mm T-slots, and Z travel of 350 mm covers plate work and small housings. Vacuum fixtures and pneumatic clamps are common on machines like this, because fast swaps matter as much as fast rapids in a hole-drilling workflow.

Typical Jobs for the VTC-600

• 3C electronics components: housings, stiffener plates, connector blocks
• Aluminium manifold blocks and distribution plates
• Small brackets and plates needing dense tapped hole patterns
• Second-operation hole work after milling on a larger centre

A phone accessory maker in Southeast Asia, for example, running aluminium plates with 40 to 60 tapped holes each, would see the cycle time difference immediately compared with a general VMC running the same program.

Footprint and Buying Notes

The machine measures about 1700 x 2350 x 2500 mm and weighs roughly 2800 kg, so two units fit in the space one VMC occupies. Control choices are Mitsubishi M80VB or Syntec; pick the one your team already programs. The BT30 tooling inventory is inexpensive compared with BT40, which lowers the real cost of adding this machine to an existing shop.

Cell Planning and Daily Care

Think about the VTC-600 as a cell component rather than a standalone machine. Because parts are small and cycles are short, the bottleneck usually sits at loading: use quick-change subplates so an operator swaps fixtures in seconds, and keep finished-part trays flowing so the machine never waits. Two VTC units with one shared operator commonly outproduce one mid-size VMC on hole-heavy work, at comparable total spend.

Daily care is light but matters in high-cycle running. Blow the BT30 taper clean at shift start, check tap and drill condition counts against your tool life log, and keep coolant concentration on the higher side of the range for tapping work. The 48 m/min rapids also raise the stakes on way covers and chip management; a daily glance at the Y-axis covers catches problems while they are still cheap. With those habits in place, the machine's job is simple: cycle after cycle of identical holes, at a rate a general VMC cannot match.
